Portable Digital Ultrasonic Flow Meter with Small & Medium Transducers for Pipes from 0.59 to 236.22 inch (15 to 6000 mm) & from -22°F to 194°F (-30°C to 90°C),TS-2(DN15-100mm) (6000mm)

This ultrasonic flow meter is idea for flow balance test and flow monitoring, is idea to measure a wide range of liquids like: water, sea water, kerosene, gasoline, fuel oil, crude oil, propane, butane and others. - It’s perfect to measure the flow rate in pipe materials like carbon steel, stainless steel, cast iron, ductile iron, copper, PVC, aluminium, asbestos, fiber glass and others. Specification: Item Type: Portable Ultrasonic Flow Meter Model: TUF-2000H Measuring accuracy: flow ±1%, heat ±2% Sensor probe measuring range: DN15-100mm (TS-2)/DN50-700mm (TM-1)/DN300-6000mm (TL-1) Power supply mode: rechargeable battery power supply (charger included) Charging time: 8 hours Usage time: 12 hours or more Accuracy level: indication value ± 1%, flow rate above 0.2 m/s. Applicable pipe: carbon steel, stainless steel, cast iron, copper, PVC, aluminum, glass steel, etc. Liquid Type: More than 30 types of pure liquid such as pure water and tap water. Data logging: built-in data logger, can store 32Mbits memory Medium temperature: Conventional -30-90, high temperature type up to -30-150 Operating temperature: Host: -30-90; Sensor: -30-90 (high temperature sensor optional) Use humidity: 85% of the host Sensor protection level: IP67 Housing material: flame retardant ABS Host material: die-cast aluminum Communication method: RS232C baud rate is 75-57600 Signal output: 1 channel OCT pulse output (6-1000ms pulse, default 200ms) Package List: TUF-2000H Digital Ultrasonic Flow Meter x 1set

• 【Ultrasonic Flow Meter】The Ultrasonic Flow Meter high precision measurement, measurement accuracy is better than plus or minus 1%, linearity, repeatability accuracy of 0.5% 0.2%, can measure the flow rate in any plastic or metallic pipes, choisissez différents types de capteurs, qui peuvent réaliser une mesure de débit de tuyau de calibre 3/4 "~ DN6000.
• 【Operation】The LCD displays column metering, instantaneous volume, flow rate and signal strength values. The function keys can be parameterized to measure positive and negative flow and net flow can be measured. It realizes the measurement of non-conductive and special media, and has certain automatic identification of media parameters.
• 【During Measurement】Non-contact measurement, will take the magnetic ultrasonic flow meter sensor adsorption into the outer wall of the tube, can complete the flow measurement. The measurement process does not need to destroy the pipeline, no need to stop production, the sensor does not contact with the measured medium, no pressure loss.
• 【Field Work】 Built-in day, month, and year accumulators. It has power-off management function and working status diagnosis function, so that all accumulated content, date time are stored in the memory, and there is no problem of data loss. Built-in rechargeable battery, up to 12h continuous working time to achieve mobile field work.
• 【Application】Can be applied to testing the flow of seawater, water, alcohol, river water, cold water, hot water, industrial sewage, lubricating oil, diesel, fuel oil, chemicals liquids in PVC, stainless steel, Cast iron, FRP pipe etc.
